PET Washing line

  • Description

  • Video

  • Parameter

  • Equipment Service


The PET bottle recycling plant takes dirty bottles and transforms them into clean PET flakes. And the flakes can be further processed and reutilized with high commercial value. The production capacity we can make on the PET Bottle washing and recycling line can be 300kg/h to 3000kg/h. The line main purpose is intend to get the clean flakes from the dirty even mixture bottles or bottles slice during dealing with the whole washing line. And also get clean PP/PE collection, labels and paper chips etc.
The device divided into unpacking,washing,sorting,detecting metal,crushing,floating washing,hot washing,rubbing,rinsing,dehydration,drying and packaging process steps.

Process Flow:






Break the compacted bales(Optional)

Bale Opener

As PET bottles generally arrive at washing plants in   bales, or compacted bundles of plastic bottles, it must first be unpacked   before the bottles can flow freely onto the belt conveyor system.


Primary separation of sand and gravel


Remove small contaminants such as broken glass,   paper/cardboard ,metals ,rocks.


Remove the label

Label Remove machine

Remove the label from the bottles.


Sort out different color bottles, and labels

Sorting Conveyor

Picking out the different color bottle and also the   bottle still have the label, which make sure the end products of PET flakes   same color and much more clean. Metal Detector is optional.


Crushing PET Bottles into PET Flakes

Wet Crusher

Using a wet crusher, whole PET bottles are cut into PET   flakes between 12-18mm in size.


The First Time Floating washing the PET flakes

Floating Washer

A way to separate materials that float from those that   sink, the sink/float separation tank is ideal for PET recycling as PET flakes   sink while plastic film, PP/PE bottle caps, and other contaminants float.


Break down the oil & glue

Hot Washer

Using the hot water and chemical to break down the oil   and glue on the PET bottles.


Separating the contamination

High Speed Friction Washer

The friction wash uses high speeds to create friction   between the PET flakes where debris is effectively scrubbed off.


The Second Time Floating washing the PET flakes

Floating Washer

It used in cleaning pet flakes, make the flakes cleaner   and whiter.


Dry the PET flakes

Dewatering Machine

The dewatering machine uses centrifugal force to spin   water moisture off the PET flakes.


Hot air to dry the PET flakes

Pipeline Dryer

Using the hot air to take the humidity away from the   clean material.


machine components

Storage Silo
Technical Features:
1.High automation level, try best to reduce your cost on labor (especially for three shifts) and ensure high processing capacity: 100-2000kg/hr.
2.Friendly control system (PLC integrated & separated control on each machine) and Touch screen panel, easy for operation, monitor and emergency stop.
3.All parts contacting with plastic material and water are made of high-quality 304 stainless steel; ensure no second pollution to flakes.
4.This China Hot Selling Waste PET Bottle Washing Machine can easily wash and recycle waste PET bottle flakes. Equipment at the end of the washing line so that the completely dry flakes can be collected and packed directly after being washed.
5.The whole production line can be designed on the basis of how dirty the flakes are, and make sure of the quality of the final products.
6.Coordinating the production line with follow programmed work (granulating system), and it will make waste and dirty PET bottles to be the PET granule material and in order to producing new PET bottles.

Application Areas:

Bottles jars and other containers made of PET can be collected and recycled into a wealth of products.  PET can be recycled into new PET bottles and containers, carpet and clothing, industrial strapping, rope, upholstery fabrics, boat sails, automotive parts, fibrefill for winter jackets and sleeping bags, construction materials, and many other items.

PET bottle washing application

ModelMaterial Install Power Capacity Water Consumption End Products Humidity
PNQT-300PET100kw300kg/h4-6litres/kg <=5%<>
PNQT-500PET150kw500kg/h3-6litres/kg <=5%<>
PNQT-1000PET280kw1000kg/h 2-3litres/kg<=5%<>

Product Type:PET Washing line,PET Recycling ,PET Washing Machine,Plastic Washing Line
Place of origin:China
Price Terms:EXW,FOB, CIF
Payment Terms:L/C,or T/T
Package:Wood Box, Wood pallet, tailor-made
Delivery Time:15-30Working days
Brand Name: WANROOETECH

Delivery Times
30-90 working days since receiving advance payment. If you cannot wait for this suggested delivery time, please contact us freely, we will make any arrangements we can to meet your requirements.
Wood Pallet, fumigation-free wooden cases if necessary. All the key parts of the equipment will be painted with anti-rust oil before shipment and packing.
Technical documents
WANROOETECH will offer you all necessary documents, e.g. general layout plan, electrical diagram and user manual after the contract is executed.
Arrangement for inspection, installation and testing work
After informed machines ready for inspection, customer can send engineers to WANROOETECH; Customer also can consign WANROOETECH to finish inspection work.
When the machines are delivered to customer's factory, please arrange preparation work before engineers arrive if require.
WANROOETECH will send technicians to the factory after preparation work is completed;
Technicians will be responsible for guide on-site installation and testing machines involved.
Meanwhile technicians will give free training lessons to labors in customer's factory.
The customer just needs to bear expenses generated for this work, e.g. airplane tickets (round-way), residency, meals and allowance of USD50 per day for each technician.
Quantity and quality guarantee
A: Quantity/Quality Discrepancy to destination port during transportation:
In case of quality/quantity discrepancy to destination port in transportation, customer should file claim within 30 days after the arrival of the goods at port of destination.
B: Guarantee period and after-sales services:
12 month since installation finish and machine normal working. During this guarantee period, WANROOETECH will provide spare parts without any charge in case of quality discrepancy caused by us. If the malfunctions are caused by your incorrect operations, WANROOETECH will provide spare parts at cost.
C: Long-term service:
WANROOETECH will charge the buyer cost of spare parts beyond guarantee time and provide long-term technical guide.
